5G Router
R2 5G Router
Want a high-performance router? The Highlink R2 5G Router is definitely a choice you shouldn’t missThis router uses zte’s self-developed chip and supports dual-card 5g card. it not only has wide coverage, but the signal is also extremely stable.Now let’s take a look at its performance!
Quick Specifications
Model No.
R2
Feature
n1/n3/n5/n7/n8/n20/n28/n34/n38/n39/n40/n41/n77/n78
Network Speed
WIFI 6 1800Mbps, 5G 3600Mbps
Battery
None
Users
Max 64
Basic Information
Model Name
CZ200
Dimension
136 × 52 × 190 mm
Weight
516g
Color
White
Air Interface
Technical Standard
Supports 5G/4G networks; Complies with 802.11 a/b/g/n/ac/ax
5G Frequency Bands
n1/n3/n5/n7/n8/n20/n28/n34/n38/n39/n40/n41/n77/n78
4G Frequency Bands
B1/B3/B5/B8/B34/B38/B39/B40/B41
Wi-Fi
Dual-band (2.4GHz & 5.8GHz); Supports WPA/WPA2/WPA3 Personal, AES-CCMP, SAE, WPS 2.0
Performance
Maximum Data Throughput
5G NR: Downlink up to 4Gbps, Uplink up to 900Mbps (theoretical)
4G LTE: Downlink up to 300Mbps, Uplink up to 50Mbps (theoretical)
4G LTE: Downlink up to 300Mbps, Uplink up to 50Mbps (theoretical)
MIMO Technology
4×4 MIMO (supports n1/n41/n77/n78 bands)
Receive Diversity
Supported
Hardware
BB Chipset
ZX298501S (2GHz main frequency)
Wi-Fi Chipset
AIC8800D80X2P (AX1800 standard)
Memory
Built-in 4Gb DDR; External 4Gb Nand
LAN/WAN Ports
4× Gigabit Ethernet ports
Power Adapter
12V 2A
SIM Card
Compatibility
Supports 3FF SIM card (SIM/USIM/UIM); Standard 6-pin
